AKW – Contour – PRIMO P12 Pump Kit D, with UPSW – 4 – 22 Trap Inc. Flowswitch

Primo XTRA shower waste pump only consisting of pump, control box, flowswitch & housing.

Quiet, unblockable & maintenance free

Contour Primo Xtra, the quiet and unblockable shower waste pump, which is maintenance free and requires no servicing, can be used with a variety of different shower tray styles including conventional level access and low level trays, floor formers and step-in, side outlet shower trays.

This silent, recyclable pumping system has been specifically designed to remove waste water from the shower tray or wet floor area, to the waste pipe where there is no direct access to a ground level drain.

Primo Xtra will easily cope with hair, shower gels and small obstructions that would normally cause a blockage.

Designed for the special needs and domestic market to meet the requirements of specifiers, installers and users. Noticeable reduction in sound output virtually eliminates noise disruption in the bathroom compared to other pumps.

• Fitted with 40mm outlet and inlet. Supplied with 2 connectors to reduce down to 22mm.
• Supplied with a flexible Installation Kit to improve pump performance.
• Significant reduction in noise.
• Self-priming, 24 volt pump.
• For optimum performance use with 22mm pipework or larger.
• Maximum drainage 12 litres per minute.
• Not handed for quick installation.
• Single speed control box, IP65 rated, can be located inside or outside the bathroom.
• No non-return valves required.
• Suitable for electric and mixer showers. Flow switch should be installed within the cold water supply, and can be fitted horizontally or vertically. (Additional flowswitch required)
• Easily adjustable run-on timer.
• 5 year warranty. (*Warranty based upon correct installation and appropriate application)
• Manufactured from parts that are 100% recyclable.
• Complies with BS7671.
• Link directly to a Mira Advance ATL Flex Extra, eliminating need for a flowswitch.
• Easy to install and set up. Comes with complete fitting instructions.
