TECHNICAL DATA
Flow Pressure: (0.1-10 bar)
Maximum Operating temperature, water: (25 °C)
Flush volume, factory setting: (5.8 & 3L)
Flush volume small, adjustment. range: (3-4 L)
APPLICATION PURPOSES
- For drywall construction
- For installation in part-height Geberit Duofix system walls
- For wall-hung WC's with connection dimensions in accordance with EN 33:2011
- For wall-hung WC's with projection up to 620mm
- For installation in par height prewall installations
- For floor constructions 0-200mm
CHARACTERISTICS
- Self-supporting frame, powder-coated
- Feet adjustable 0-200mm
- Foot plate depth suitable for installation in U-profiles UW 50 and UW 75 and Geberit Duofix system rails
- Concealed cistern with front actuation
- Immediate post flush possible with factory setting
- Tool-free installation and maintenance work on concealed cistern
- Protection box for service opening can be cut to length
- Frame prepared for support brackets for WC ceramic appliances with small contact surfaces
- Non-slip leg supports
- Connection bend can be mouinted without tools at different depths, adjustable range 45mm
- Concealed cistern fully insulated against condensation
- Flush bend fitted
- Water supply connection on the near centre
- Equipped with conduit pipe for feed pipe for connection of Geberit AquaClean shower toilets
- Galvanized feet
- Rotatable foot plates
- Fastening for connection bend, sound-absorbing
- Cistern fulfils standard requirements in accordance with EN 14055, Class 2
- Cistern rotatable by 180 Degrees for access from service room
- Protection cover box for service opening protects against moisture and dirt
- With fastening option for electrical connection
SCOPE OF DELIVERY
- Water supply connection Rp 1/2" - R 1/2", compatible with MF, with integrated angle stop valve and hand wheel
- Protection box for service opening
- 2 wall anchors
- Connection set for WC, 90mm
- Connection bend 90 Degree made of PE-HD, 90mm
- Adaptor socket made of PE-HD, 90 / 110mm
- 2 protection plugs
- Cup for flush volume reduction 4.0 / 2.6L
- 2 threated rods M12
- Fastening material
